Also know as Grade 5 Titanium.
Bearing the highest strength-to-weight ratio of any metal, Ti-6Al-4V is ideal for lightweight applications and has both high tensile strength and fatigue resistance.
Also known as Grade 5 titanium, Ti-6Al-4V is ideal for lightweight applications requiring high tensile strength and corrosion resistance. It is widely used in aerospace applications such as airframe components and jet engines. Check out the materials tech specs section below to learn more.
100 Micron – 0.1 mm
330 x 270 x 200 mm
( 12.9 x 10.5 x 7.8 in )
Properties | Sintered | Wrought Heat Treated |
---|---|---|
0.2% Compressive Yield Strength | 900 MPa | — |
Elastic Modulus | 180 GPa | 190 GPa |
Hardness | 52 HRC | 63 HRC |
Relative Density | > 94.5% | 100% |
